Description
Product Details:
- Product name: JPC 3-42 A-C-BBVP
- Product No: 98601006
- EAN number: 5711497397258
Technical:
- Max. head: 42 m
- Primary shaft seal: BBVP
- Approvals: CE
- Curve tolerance: ISO9906:2012 3B
- Pump version: A
- Model: A
- Ejector valve: no
Materials:
- Pump housing: COMPOSITE
- Impeller: Composite
- Material code: C
Installation:
- Range of ambient temperature: -10 .. 40 °C
- Maximum operating pressure: 6 bar
- Maximum permissible inlet pressure: 2 bar
- Pump inlet: G1
- Pump outlet: G1
Liquid:
- Pumped liquid: Water
- Liquid temperature range: 0 .. 35 °C
- Selected liquid temperature: 20 °C
- Density: 998.2 kg/m³
Electrical data:
- Power input – P1: 720 W
- Rated power – P2: 0.441 kW
- Mains frequency: 50 Hz
- Rated voltage: 1 x 220-240 V
- Rated current: 3.12 A
- Capacitor size – run: 12 µF/450 V
- Enclosure class (IEC 34-5): IP44
- Insulation class (IEC 85): F
- Type of cable plug: NONE
- Cable: Y
Controls:
- Presscontrol: without press control
- Switch: on/off switch not included
Others:
- Net weight: 8 kg
- Gross weight: 9 kg
- Shipping volume: 0.026 m³
