Description
Technical:
- Shaft diameter: 42 mm
- Length of shaft end: 110 mm
- Approvals for motor: CE, UKCA, EAC, SEPRO, cURus/cCSAus, Morocco
- Energy approvals for motor: CE, CEI, CC, KEMCO, Singapore, Nigerian, JIS, Aust./N. Z.
- Model: H3
- Cooling: IC 411
- Measuring Equip: SVANTEK, SVAN 958
- Cable gland entry: 2xM20 + 4xM40 knock out
- Drain holes: Yes (closed)
Installation:
- Range of ambient temperature: -30 .. 60 °C
- Flange size for motor: FF300
Electrical data:
- Motor standard: IEC
- Motor type: 160LB
- Rated power – P2: 18.5 kW
- Mains frequency: 50 Hz
- Rated voltage: 3 x 380-415D V
- Rated current: 34.5-33.5 A
- Maximum current consumption: 38.0-36.5 A
- Starting current: 700-980 %
- Cos phi – power factor: 0.89-0.85
- Rated speed: 2940-2950 rpm
- Rated full-load torque: 60.0-60.0 Nm
- Locked-rotor torque: 200-250 %
- Breakdown torque: 350-430 %
- Moment of inertia: 0.058 kg m²
- IE Efficiency class: IE3
- Motor efficiency at full load: 92.4 %
- Motor efficiency at 3/4 load: 93.2-93.0 %
- Motor efficiency at 1/2 load: 93.2-92.2 %
- Number of poles: 2
- Enclosure class (IEC 34-5): S5 Dust/Jetting
- Insulation class (IEC 85): F
- Built-in motor protection: PTC
- Tropic protec: no
- Thermal protec: external
- R1: 0.45 Ohm
- R2: 0.45 Ohm
- R3: 0.45 Ohm
- Winding 1: PHASE 1
- Winding 2: PHASE 2
- Winding 3: PHASE 3
- Mount. design. acc. IEC 34-7: IM B35
- Lubricant type: UNIREX N3
- Lubricant quan: 13 g
- Temperature 1: 2000 H / 40 °C
- Temperature 2: 2300 H / 60 °C
- Bearing insulation type N-end: Steel Bearing
Others:
- Net weight: 113 kg
- Colour/type: NCS 9000 gloss 40+-10 / E-coat
- Country of origin: HU
- Custom tariff no.: 8501.52.00.00
- Environmental approvals for motor: WEEE
